Part No: 3H45W2SAM99A30X
Product Description
- D-SUB Combination Standard
- 45W2 [••••••••••••••••••••••○○•••••••••••••••••••••]
- Socket
- Solder cup
- Threaded Insert
| Termination signal [e.g. clamp, crimp, solder, SMT] |
Solder cup |
| Hardware options termination side |
Threaded Insert |
| Dielectric with standing voltage signal |
1000 V |
| Dielectric with standing voltage power |
1000 V |
| min. working temperature |
-55° C |
| max. working temperature |
+125° C |
| Working voltage power |
250 V |
| Insertion force |
160 N |
| Extraction force |
22 N |
| Insulator material |
PBT GF UL 94 V-0 |
| Insulator color |
Green |
| Shell material |
Steel |
| Shell plating |
Tin |
| Signal contact material |
Copper alloy |
| Plating signal contact (mating area) |
Gold over nickel |
| Mounting option material |
Copper Alloy |
| Plating mounting option |
Nickel |
| Standard mating cycles |
IEC 60807-2 |
| Standard IP rating |
IEC 60807-2 |
| Standard current rating |
IEC 60807-2 |
| Standard insertion / extraction force |
IEC 60807-2 |
| Standard dielectric voltage |
IEC 60807-2 |
| Standard working voltage |
IEC 60807-2 |
