Part No: 163A14459X
Product Description
- D-SUB Standard
- 25-pos.
- Plug
- Solder pin straight
- Threaded rear spacer
- Quality class 3
- UNC 4-40
| Termination signal [e.g. clamp, crimp, solder, SMT] |
Solder pin straight |
| Thread type |
UNC 4-40 |
| Hardware options mating side |
Threaded insert |
| Hardware options termination side |
Threaded rear spacer |
| Dielectric with standing voltage signal |
1000 V |
| Quality class |
Quality class 3 |
| Mating cycles |
50 |
| IP rating |
IP 20 |
| Insertion force |
<83 N |
| Contact resistance standard |
10 mOhm |
| min. working temperature |
-55° C |
| max. working temperature |
+125° C |
| Insulator material |
PBT GF UL 94 V-0 |
| Insulator color |
Black |
| Shell material |
Steel |
| Shell plating |
Tin |
| Signal contact material |
Copper alloy |
| Plating signal contact (termination area) |
Gold over nickel |
| Plating signal contact (mating area) |
Gold over nickel |
| Mounting option material |
Steel |
| Plating mounting option |
Nickel |
| Standard mating cycles |
IEC 60807-2 |
| Standard insertion / extraction force |
IEC 60807-2 |
| Standard dielectric voltage |
IEC 60807-2 |
| Standard working voltage |
IEC 664-1 |
